Description :
| CPU | Intel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
| Chipset | Intel® H110 |
| Expansion Slots | 1 x PCIe 3.0/2.0 x16 (x16 mode, gray) 2 x PCIe 2.0 x1 |
| PCI | 3.0 |
| Internal I/O Ports | 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x Clear CMOS jumper(s) 1 x 14-1 pin TPM connector |
| Memory Slots | 2 |
| Memory Type | DDR4 |
| USB | Intel® H110 chipset : 6 x USB 2.0/1.1 port(s) (4 at back panel, black, Type-A, 2 at mid-board) Intel® H110 chipset : 4 x USB 3.1 Gen 1 port(s) (2 at back panel, blue, Type-A, 2 at mid-board) |
| Audio | Realtek ALC887/897 8-Channel High Definition Audio CODEC *1 – Supports : Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : – LED-illuminated design – Audio Shielding – Dedicated audio PCB layers – Premium Japanese-made audio capacitors |
| Maximum Memory | 32 |
| BIOS | 128 Mb Flash ROM |
| Form Factor | m-atx |
| Warranty | 3 years Replacement |
| Product Code |
55230 |
|---|---|
| Product Size |
No Product Size |
| Product Color |
No Product Color |
